Kartakou EXP-01 Expression Pedal

Almost every guitar processor user desires to expand the possibilities of his setup. With EXP-01 you'll be able to operate with volume, delay length, gain level, panning, and any other features your processor provides.

Built in a well-known solid metal housing and equipped with the best components, it delivers smooth movement and precise parameter adjustment. A linear potentiometer is an ideal solution for almost all guitar devices and provides even parameter adjusting all the way. Toe-switch with a decent click also adds an additional layer of control to your presets.

EXP-01 Expression Identities

  • Life-long engineering
    We found the most durable ceramic dust-proof potentiometer and silver-coated-contact switch on the market and set the pedal with them. EXP-01 stays its ground when others leave the race and need servicing.
  • Toe-switch
    With a momentary switch, you are able to control not only parameters like volume and wah, delay time, and reverb mix, but also switch between different presets and turn effects on and off.

  • Universal Operating
    EXP-01 is incredibly versatile. You can hook it up with TS-style devices (Line 6, etc.) or TRS-style devices (Fractal, Headrush, Kemper, etc.), Tip-hot or ring-hot operation is an option too.
  • Hand Built
    We believe machines are good. However human beings are unbeatable. Handcrafting adds a certain feel to every assembled device. All of our creations have lots of human work.
EXP-01 Connection and Controls
Potentiometer - 1/4 TRS jack potentiometer output.
Switch - 1/4 TRS jack potentiometer output.

TRS/TS - defines TS or TRS potentiometer operating mode.
Internal DIP Switch - defines Tip-Hot or Ring-Hot operating modes for TRS-style devices.
