Warmer Controls
Gain - sets the amount of overdrive. Right is more, left is less.
Tone - sets the tone of the pedal. Right is brighter, left is darker.
Volume - sets the output volume. Left is less volume, right is more.
Left Face Switch - sets Boost or Overdrive modes. Upper switch position activates Overdrive mode. Bottom switch position activates Boost mode.
Middle Face Switch - sets clipping style. Upper switch position activates Crunchy clipping style. Bottom switch position keeps soft clipping style. Makes no effect in Boost mode.
Right Face Switch - activates low frequencies comeback in the upper position.
Internal Lights Switch - activates lighting rim.
Internal Bypass Switch - defines passive or active J-Fet bypass mode.
Warmer Specification
Dimensions
Warmer sizes are 113*61*49 mm (height with knobs) and weight is 0.255 kg
Power Supply
Use a 9V DC center negative power adapter only. Maximum pedal current consumption is 50 mA.
Don't use higher voltage or unstabilized power adapters. This may damage the pedal.
Warranty
Pedal comes with 2-year full warranty.
